HP Series

General Technical Data

• Input power

  0.75~75KW

• Max Flow

  Up to 360m3/h

• Max Pressure

  16 Bar

• Voltage

  220V/380V

Description

INSTALLATIONS AND USE

. For pumping clean liquids without abrasive particles, which are chemically non aggressive to the pump materials

. For water supply

. For heating, air-conditioning, cooling and circulation plants

. For civil and industrial applications

. For firefighting applications

. For irrigation

. The pump should be installed in an enclosed environment or sheltered from inclement weather

PERFORMANCE RANGE

. Flow rate up to 360m3/h

. Head up to 99.5m

OPERATING CONDITIONS

. Liquid temperature up to +80°C

. Ambient temperature up to +40°C

. Max. Working pressure 16bar

. Continuous duty

OPTIONS AVAILABLE ON REQUEST

. Special mechanical seal

. Other voltages or 60Hz frequency

. Higher or lower liquid temperatures

ELECTRIC MOTOR

. Two-pole induction motor, 50Hz (n = 2850rpm)

. Single phase 220V-240V, maximum 2.2kW

. Three phase 380V-415V

. With thermal protector incorporated into the winding

. Insulation class F

. Protection IP55
